Company Advantages1. The quality of TBF is guaranteed. It undergoes a field site test to check its sunlight absorptivity, energy storage as well as its energy utilization. It is granted with appearance design patents and utility model patents
2. From the long run, using this product helps people lower the risk of illnesses. This will eventually contribute to their health and comfort of living. With a firm and solid structure, it is anti-collision
3. The exertion of depends on the great performance of truck roll up door . Made of strong materials, it is high-strength
4. By improving the manufacturing technology, truck roll up door now gains more and more attention at home and abroad. It is characterized by high dimensional stability
5. truck roll up door are usually , so it's to give them a try. The product is convenient to fix and hard to shift
◆ Suitable height of door: 0.5M-4M.
◆ Suitable width of door: 0.5M-5M.
◆ Working environment temperature: -40℃---+60℃.
◆ Handle type: Tube typeORhandle type.
◆ Material technology: Extrusion.
◆ Slider design process: Since the spring type.
◆ Curtain piece design process: Double back arc.
◆ Connection plate design process: Card button.
◆ Opening mode: You can choose any of the five ways to open it.
◆ Matching roller specifications: 80 mmx1 Φ. 2 mm.
◆ Installation method: Fasten with a bolt OR rivet.
1) Confirm the whole frame of width and height is consistent with the drawings, a diagonal dimension is uniform around the mouth of the cave.
2) In the condition that the size right to start the installation shutter connection plate.
3) When installing a connection plate to ensure about connection plate is in the same horizontal plane and vertical plane.
4) Around a fixed connection plate respectively.
5) The card button u-shaped seat in a connection plate.
6) Puts drum u-shaped seat.
7) Connect the ribbon with the curtain on a cylinder.
8) Connection, after put down gently sliding door, door lock cylinder torsion pin will fall off.9) Clip the door into the left and right side guide rail and fix it on the frame.
Remind
The thickness of the door frame on the upper end of the hole height should not be greater than 10MM!
Due to different measurement methods, the measurement is allowed to be within 1mm-3mm error.
Due to the different colors displayed by different computers, the color of the actual product may be slightly different from the above image, affected by the physical object, thank you for your understanding.
Company Features1. After focusing on truck roll up door for many years,
TRUCK BODY FITTINGS CO., LTD. gained recognition of the industry people.
2. The factory production line of TRUCK BODY FITTINGS CO., LTD. are all under international standard.
3. TBF always sticks to customer first. Contact!
