high-quality aluminum roller shutter door vanrefrigerated supply for Trialer

Company Advantages
1. The TBF is produced using quality raw materials and smart technology. It is less likely to leave dents on the product
2. TRUCK BODY FITTINGS CO., LTD. is able to provide customers with good products, excellent technical support and perfect after-sales service. It is exported to over 30 countries and regions in the world
3. Our professional team implements quality control system to meet the most strict quality standards. It is very easy to install and use

Product Feature

◆ Suitable height of door: 0.5M-4M.

◆ Suitable width of door: 0.5M-5M.
◆ Working environment temperature: -40℃---+60℃.
◆ Handle type: Tube typeORhandle type.
◆ Material technology: Extrusion.
◆ Slider design process: Since the spring type.
◆ Curtain piece design process: Double back arc.
◆ Connection plate design process: Card button.
◆ Opening mode: You can choose any of the five ways to open it.
◆ Matching roller specifications: 80 mmx1 Φ. 2 mm.
◆ Installation method: Fasten with a bolt OR rivet.

TBF high-quality aluminum roller shutter door supply for Trialer-1

Product Display

TBF high-quality aluminum roller shutter door supply for Trialer-2

TBF high-quality aluminum roller shutter door supply for Trialer-3

TBF high-quality aluminum roller shutter door supply for Trialer-4

TBF high-quality aluminum roller shutter door supply for Trialer-5

Suggestions For Door Installation

TBF high-quality aluminum roller shutter door supply for Trialer-6

1) Confirm the whole frame of width and height is consistent with the drawings, a diagonal dimension is uniform around the mouth of the cave.
2) In the condition that the size right to start the installation shutter connection plate.
3) When installing a connection plate to ensure about connection plate is in the same horizontal plane and vertical plane.
4) Around a fixed connection plate respectively.
5) The card button u-shaped seat in a connection plate.
6) Puts drum u-shaped seat.
7) Connect the ribbon with the curtain on a cylinder.
8) Connection, after put down gently sliding door, door lock cylinder torsion pin will fall off.9) Clip the door into the left and right side guide rail and fix it on the frame.

Drawing

TBF high-quality aluminum roller shutter door supply for Trialer-7

TBF high-quality aluminum roller shutter door supply for Trialer-8

TBF high-quality aluminum roller shutter door supply for Trialer-9

Remind

TBF high-quality aluminum roller shutter door supply for Trialer-10

Remind

The thickness of the door frame on the upper end of the hole height should not be greater than 10MM!
Due to different measurement methods, the measurement is allowed to be within 1mm-3mm error.
Due to the different colors displayed by different computers, the color of the actual product may be slightly different from the above image, affected by the physical object, thank you for your understanding.

Product Details

TBF high-quality aluminum roller shutter door supply for Trialer-11

TBF high-quality aluminum roller shutter door supply for Trialer-12

TBF high-quality aluminum roller shutter door supply for Trialer-13

TBF high-quality aluminum roller shutter door supply for Trialer-14

Company Features
1. By supplying aluminum roller shutter door and professional service, TBF now ranks top in the market. TRUCK BODY FITTINGS CO., LTD. is equipped with strong research strength, having an R&D team dedicated to developing all types of new aluminum roll up door .
2. We are not the only one company to produce aluminium roller shutter , but we are the best one in term of quality.
3. Our automatic roll up door production equipment possesses many innovative features created and designed by us. has a great appeal to TRUCK BODY FITTINGS CO., LTD. as a business tenet. Check now!

g******z

TBF aluminum roller shutter door has passed the necessary assessments. They may include part tolerances, size limitations, materials properties, mechanical analysis, function realization, etc. Its compact design and high integration make it an excellent fit for small- and medium-sized sites

w******a

The quality test for TBF automatic roll up door must be conducted. It has to go through a check for start-up and pause performance before delivery. It suits both engineering companies and equipment rental companies

d******z

TBF aluminium roller shutter stands out in the market thanks to its humanized design. It is created based on the combined concept of features of human cleaning action and maneuverability. The product has been so successful that its name has become widely acknowledged in the engineering industry

q******b

TBF automatic roll up door has passed both domestic and foreign electric standards. The electric components, such as the plug and wires, and housing are all made of materials that conform to related requirements. It is proudly manufactured by Unique Group with the scientific and technological innovation accumulated over the past 30 years

u******e

TBF aluminium roller shutter conforms to the electrical safety standards. Its wires and cables, plug, switching power system, and electric components such as conductor and resistor are tested to comply with relevant standards. It can be manufactured upon our on-site surveying, which ensures that it suits the needs of your project

r******h

The product meets the most stringent quality requirements and can be used for quite a long time. It significantly reduces manpower costs
