top custom van parts door factory for Truck

Company Advantages
1. This model of custom van parts is efficient and durable thanks to the design of . The product itself has a heat-resisting property
2. The use of this product benefits both workers and manufacturers. It helps workers reduce working fatigue, and cuts down unnecessary labor costs for manufacturers. It is exported to over 30 countries and regions in the world
3. Strict internal quality control system to ensure that products meet international standards. The product is convenient to fix and hard to shift

Product Feature

◆ Suitable carriage height: The height of the carriage is more than 1.5m.
◆ Suitable carriage temperature: Normal temperature.
◆ Handle type: "-" shaped handle.
◆ Lock head / lock seat technology: Forging /casting.
◆ Lock nose design technology: Reserve the lock core hole position.
◆ Installation: Bolting.

top custom van parts door factory for Truck-1

Product Display

top custom van parts door factory for Truck-2

top custom van parts door factory for Truck-3

top custom van parts door factory for Truck-4

top custom van parts door factory for Truck-5

Welding Lock Bar Recommendations

top custom van parts door factory for Truck-6

1) To confirm the distance between the top and bottom frame lock block center distance.
2) Are fixed on a flat surface based on size and lock after.
3) To ensure that the height size, respectively fixed frame, to ensure that the center of the products are highly consistent.
4) According to the length of the tail and locks the height to the length of the weld pipes under.
5) Spot welding pipe and locks, up and down two locks respectively and spot welding pipe.
6) remove the tube and spot welding of locks, confirm the lock rod with two locks all the verticality, after.
7) On the shelf two Y type rotary burn, welding.

Remind

top custom van parts door factory for Truck-7

Remind

The hole height is between 1500MM and 2500MM, you can refer to this door lock!
Due to different measurement methods, the measurement error is allowed between 5MM and 30MM.
Due to the different colors displayed by different computers, the actual colors of products may be slightly different from the above images, which are affected by physical objects. Thank you for your understanding.

Door Locking Gear Series

Part No.	Part Name	Quantity	Part No.	Part Name	Quantity
011011-In	Keeper	2	011017.1-In	Hand Hub	1
011022-In	Cam	2	011017-In	Handle Rivet	1
011023-In/24-In	Large Bearing Bracket	2	011018-In	Retainer Catch	1
011015-In/16-In	Small Bearing Bracket	1	011001-In(Optional)	Tube ∮27 x 2.5	1

Product Details

top custom van parts door factory for Truck-8

top custom van parts door factory for Truck-9

top custom van parts door factory for Truck-10

top custom van parts door factory for Truck-11

Product Application

top custom van parts door factory for Truck-12

top custom van parts door factory for Truck-13

top custom van parts door factory for Truck-14

top custom van parts door factory for Truck-15

Company Features
1. TRUCK BODY FITTINGS CO., LTD., which is committed to corporating innovation, is a diversified enterprise group that focuses on the creativity, design and marketing of custom van parts .
2. All our technician in TRUCK BODY FITTINGS CO., LTD. are well trained to help customers solve problems for lock body .
3. Our company is committed to reducing the environmental impact of our businesses and promoting the sustainable development of natural resources. To achieve this mission, we will conduct business in accordance with applicable environmental laws, regulations, and policies.
